| Designation | KBW240-230V¹ |
|---|
| Option model | Standard |
| Order number | 9020-0338 |
| Data |
| Serie | KBW |
| Performance Data Temperature |
| Temperature fluctuation with 100% illumination [± K] | 0.2 |
| Temperature fluctuation without illumination cassettes [± K] | 0.1 |
| Temperature range with 100% illumination [°C] | 5…60 |
| Temperature range without illumination cassettes [°C] | 0…70 |
| Temperature variation with 100% illumination [± K] | 0.5 |
| Temperature variation without illumination cassettes [± K] | 0.5 |
| Lightdata per Illumination Cassettes |
| Arabidopsis lamps [lx]* | 11000 |
| Arabidopsis lamps [W/m²]* | 32 |
| Daylight tubes [lx]* | 9000 |
| Daylight tubes [W/m²]* | 24 |
| Fluora® growth lamps [lx]* | 7500 |
| Fluora® growth lamps [W/m²]* | 23 |
| Electrical data |
| Nominal power [kW] | 1.4 |
| Phase (Nominal voltage) | 1~ |
| Power frequency [Hz] | 50 |
| Rated Voltage [V] | 200…240 |
| Unit fuse [A] | 16 |
| Doors |
| Inner doors | 1 |
| Unit doors | 1 |
| Housing dimensions not incl. fittings and connections |
| Depth net [mm] | 800 |
| Height net [mm] | 1465 |
| Width net [mm] | 925 |
| Internal Dimensions |
| Depth [mm] | 485 |
| Height [mm] | 785 |
| Width [mm] | 650 |
| Measures |
| Interior volume [L] | 247 |
| Load per rack [kg] | 30 |
| Net weight of the unit (empty) [kg] | 202 |
| Permitted load [kg] | 100 |
| Wall clearance back [mm] | 100 |
| Wall clearance sidewise [mm] | 100 |
| Environment-specific data |
| Energy consumption at 37 °C and with illumination [Wh/h] | 450 |
| Sound-pressure level [dB(A)] | 53 |
| Fixtures |
| Number of illumination cassettes (std./max.) | 2/2 |
| Number of shelves (std./max.) | 2/7 |
| Performance Data Temperature |
| Temperature fluctuation with 100% illumination [± K] | 0.2 |
| Temperature fluctuation without illumination cassettes [± K] | 0.1 |
| Temperature range with 100% illumination [°C] | 5…60 |
| Temperature range without illumination cassettes [°C] | 0…70 |
| Temperature variation with 100% illumination [± K] | 0.5 |
| Temperature variation without illumination cassettes [± K] | 0.5 |
| Lightdata per Illumination Cassettes |
| Arabidopsis lamps [lx]* | 11000 |
| Arabidopsis lamps [W/m²]* | 32 |
| Daylight tubes [lx]* | 9000 |
| Daylight tubes [W/m²]* | 24 |
| Fluora® growth lamps [lx]* | 7500 |
| Fluora® growth lamps [W/m²]* | 23 |
| Electrical data |
| Nominal power [kW] | 1.4 |
| Phase (Nominal voltage) | 1~ |
| Power frequency [Hz] | 50 |
| Rated Voltage [V] | 200…240 |
| Unit fuse [A] | 16 |
| Doors |
| Inner doors | 1 |
| Unit doors | 1 |
| Housing dimensions not incl. fittings and connections |
| Depth net [in] | 31.52 |
| Height net [in] | 57.7 |
| Width net [in] | 36.45 |
| Internal Dimensions |
| Depth [in] | 19.11 |
| Height [in] | 30.93 |
| Width [in] | 25.61 |
| Measures |
| Interior volume [cu.ft.] | 8.7 |
| Load per rack [lbs] | 66 |
| Net weight of the unit (empty) [lbs] | 445 |
| Permitted load [lbs] | 220 |
| Wall clearance back [in] | 3.94 |
| Wall clearance sidewise [in] | 3.94 |
| Environment-specific data |
| Energy consumption at 37 °C and with illumination [Wh/h] | 450 |
| Sound-pressure level [dB(A)] | 53 |
| Fixtures |
| Number of illumination cassettes (std./max.) | 2/2 |
| Number of shelves (std./max.) | 2/7 |
